LSAW & SSAW Steel Pipe
SSAW Spiral Welded Steel Pipe
Spiral submerged-arc welded pipe OD 219-3500mm, wall 6-28mm, to API 5L X42-X70 and GB/T9711 - for water, oil and piling applications.
Specifications
- Outer Diameter
- 219-3500 mm
- Wall Thickness
- 6-28 mm
- Length
- 6-30 m
- Standards
- API 5L GR.A/B X42-X70, SY/T5037, GB/T9711
- Steel Grades
- Q235B, Q355B
Economical Large-Diameter Pipe
Spiral submerged-arc welded pipe reaches OD 219-3500mm with wall 6-28mm and lengths to 30m - the economical choice for water transmission, piling and low-to-medium pressure lines at volume.
Standards and Grades
Production covers SY/T5037, GB/T9711 and API 5L grades A, B and X42-X70 in Q235B and Q355B. LSAW longitudinal pipe (OD 325-1422mm, wall 6-40mm) is available where the specification requires it.
Buyer Tip: Confirm Line-Pipe vs Piling Duty
Piling and structural use accepts SY/T5037 class material at a lower cost; water and oil transmission usually requires GB/T9711 or API 5L PSL levels. Confirm the duty class before comparing prices.
