Butt-Weld Elbows: 90 LR, 45, Short Radius and 180 Degree Returns (ASME B16.9)
The complete direction-change family to ASME B16.9, EN 10253-4, GB/T 12459 and JIS B2313: 90 degree long radius (R=1.5D), 45 degree, 90 degree short radius (R=1.0D) and 180 degree return bends (LR/SR), DN15-DN600, wall schedules Sch 5S-160 matched to your pipe. Supplied pickled and passivated with s
Specifications
- Types
- 90LR, 45LR, 90SR, 180 degree returns
- Size Range
- DN15-DN600 (NPS 1/2-24)
- Wall Schedule
- Sch 5S, 10S, 40S, 80S, 160
- Standards
- ASME B16.9, EN 10253-4, GB/T 12459, JIS B2313
- Reference Weight
- 180 degree return approximately twice the 90LR elbow
- Certificate
- EN 10204 3.1, PMI on request
Product Overview
The complete direction-change family to ASME B16.9, EN 10253-4, GB/T 12459 and JIS B2313: 90 degree long radius (R=1.5D), 45 degree, 90 degree short radius (R=1.0D) and 180 degree return bends (LR/SR), DN15-DN600, wall schedules Sch 5S-160 matched to your pipe. Supplied pickled and passivated with standard butt-weld bevel or to your piping specification. Standard raw material grades ASTM A403 TP304/304L, 316/316L; duplex 2205, super duplex 2507, nickel alloys and 316Ti available on request - customised fittings in special materials are our specialty (see our Customized Fittings Experts page).
Specifications and Standards
90LR, 45LR, 90SR, 180 degree returns; DN15-DN600 (NPS 1/2-24); Sch 5S, 10S, 40S, 80S, 160; standards ASME B16.9, EN 10253-4, GB/T 12459, JIS B2313; 180 degree return weight approximately twice the 90LR elbow; certificates EN 10204 3.1 with PMI on request.
Applications
Direction changes in food and beverage, pharma, water treatment, chemical and energy piping; 180 degree returns for serpentine heating and cooling circuits.
Request a Quote
Send size, schedule or class, material grade and quantity to melinda@spai-steel.com - we reply with a confirmed supply proposal and lead time.
